![Vacuum motor - Ametek [230 Volt] [1450 Watt]](https://demo.cleanpart.se/wp-content/uploads/116136-00-1.webp)
| Brands | Ametek |
|---|---|
| Type | Tangential By Pass |
| Current | AC |
| Volt | 230 Volt |
| Watt | 1450 Watt |
| Steps | 3 |
| Max RPM | 20891 |
| Discharge type | Exhaust pipe |
| Height total height (mm) | 198 mm |
| Height turbine housing (mm) | 87.5 mm |
| Diameter turbine house (mm) | 183 mm |
| Diameter fan housing (mm) | 85.3 mm |
| Diameter exhaust pipe OD (mm) | 51 mm |
| Diameter exhaust pipe ID (mm) | 46 mm |
| Cables On Motor | Yes |
| Cable Connectors | No connectors |
| Mounting holes | 3 |
| Height mounting holes (mm) | 63 mm |
| Size - Intake pipe (mm) | (-) |
| Carbon brush no | 33415-3 |
| Width carbon brushes (mm) | (-) |
| OEM | 116136-00 |
