![Vacuum motor - Ametek Lamb Electric [36 Volt] [1175 Watt]](https://demo.cleanpart.se/wp-content/uploads/117227-00-1.webp)
![Vacuum motor - Ametek Lamb Electric [36 Volt] [1175 Watt] - Image 2](https://demo.cleanpart.se/wp-content/uploads/117227-00-2.webp)
![Vacuum motor - Ametek Lamb Electric [36 Volt] [1175 Watt] - Image 3](https://demo.cleanpart.se/wp-content/uploads/117227-00-3.webp)
Fimap Magna 1300
Fimap Magna 1300 D
| Brands | Ametek Lamb Electric |
|---|---|
| Type | Peripheral By Pass |
| Current | DC |
| Volt | 36 Volt |
| Watt | 1175 Watt |
| Steps | 3 |
| Max RPM | 14497 |
| Discharge type | Gills |
| Height total height (mm) | 239 mm |
| Height turbine housing (mm) | 111.5 mm |
| Diameter turbine house (mm) | 191 mm |
| Diameter fan housing (mm) | 94 mm |
| Width carbon brushes (mm) | 137 mm |
| Cables On Motor | Yes |
| Cable Connectors | No connectors |
| Height mounting holes (mm) | (-) |
| Mounting holes | No mounting holes |
| Diameter exhaust pipe ID (mm) | (-) |
| Diameter exhaust pipe OD (mm) | (-) |
| Carbon brush no | CO409401 |
| Size - Intake pipe (mm) | (-) |
| OEM | 117227-00, 117505-13, 40750 |
