Cleanfix RA330 IBC
| Brands | Ametek |
|---|---|
| Type | Peripheral By Pass |
| Current | DC |
| Volt | 12 Volt |
| Watt | 200 Watt |
| Steps | 1 |
| Discharge type | Gills |
| Height total height (mm) | 132 mm |
| Height turbine housing (mm) | 44 mm |
| Diameter turbine house (mm) | 130 mm |
| Diameter fan housing (mm) | 86.5 mm |
| Width carbon brushes (mm) | 116 mm |
| Size - Intake pipe (mm) | 31×38 mm |
| Cables On Motor | No |
| Height mounting holes (mm) | (-) |
| Cable Connectors | No connectors |
| Carbon brush no | (-) |
| Mounting holes | No mounting holes |
| Diameter exhaust pipe ID (mm) | (-) |
| Diameter exhaust pipe OD (mm) | (-) |
| Max RPM | (-) |
| OEM | 61108.20059 |
