![Vacuum motor - Ametek [230 Volt] [1450 Watt]](https://demo.cleanpart.se/wp-content/uploads/3023012-1.webp)
![Vacuum motor - Ametek [230 Volt] [1450 Watt] - Image 2](https://demo.cleanpart.se/wp-content/uploads/3023012-2.webp)
![Vacuum motor - Ametek [230 Volt] [1450 Watt] - Image 3](https://demo.cleanpart.se/wp-content/uploads/3023012-3.webp)
| Brands | Ametek |
|---|---|
| Type | Peripheral By Pass |
| Current | AC |
| Volt | 230 Volt |
| Watt | 1450 Watt |
| Steps | 3 |
| Discharge type | Gills |
| Height total height (mm) | 198 mm |
| Height turbine housing (mm) | 95 mm |
| Diameter turbine house (mm) | 144 mm |
| Diameter fan housing (mm) | 78 mm |
| Width carbon brushes (mm) | 137 mm |
| Height mounting holes (mm) | (-) |
| Cables On Motor | Yes |
| Carbon brush no | (-) |
| Cable Connectors | No connectors |
| Diameter exhaust pipe ID (mm) | (-) |
| Mounting holes | No mounting holes |
| Diameter exhaust pipe OD (mm) | (-) |
| Max RPM | (-) |
| Size - Intake pipe (mm) | (-) |
| OEM | 3023012, 060800004.01, 6110950001 |
